ACP OpDesign

overview

ACP OpDesign revolutionizes the product design and development process through a holistic, performance driven method. Based on the advanced SPDRM (Simulation Process Data and Resources Manager) process management software of BETA CAE Systems, it captures ETA’s Accelerated Concept to Product (ACP) Process and delivers a streamlined optimization-led design path.

ACP OpDesign is enabled by combining the power of ANSA’s modeling capabilities with its connection to the most well-known finite element analysis (FEA) solvers, topology, parametric optimizers and META’s post-processing automation. Additional features also allow the user to:

  • Create new products from concepts.
  • Optimize existing designs.
  • Evaluate numerous design concepts under multiple load conditions
  • Optimize shape, material and thickness
  • Consider manufacturability alternatives

Concept

Starting from concept, the available design space is defined and set-up for topology optimization under multidisciplinary loads (static and dynamic). The shell geometry from the results is generated by allocating material where it is needed to withstand.

Low Fidelity 3G (LF3G)

From conceptual design or continuing with existing designs, LF3G focuses on the optimization of geometry, grade, and gauge. This step optimizes the position of important parts, the width and height of cross sections, various types of material and its grades.

High Fidelity 3G (HF3G) for Substructuring and Decoupling

The load carrying substructure or sub-systems are “decoupled” for detailed design, based on alternative manufacturing design solutions and weight reduction. The sub-systems are further optimized for the optimal design solution under multiple load cases. Further, the system has fully reintegrated gauges optimized if required.
